Fiber Optic Splice closure 24cores

Basic Data of Fiber Optic Splice closure 24cores

Product No.:CL-FTTH-SC24

Delivery Time: 15-20 days

MOQ(Neutral): 100pcs

Package: -

Payment Term: Western Union, Paypal,T/T

  • cl ftth sc24 1

Application of Fiber Optic Splice closure 24cores

This product provides suitable for cable whose diameter is within 22mm.It can be used in aerial,duct and direct buried application as well as the all-plastic local cable connection.

Structural features of Fiber Optic Splice closure 24cores

  • It complies with the regulations of YD/T814-1996.
  • The shell material is high quality engineering plastic(ABS),which is anti-aging,anti-corrosion and thunder-proof.
  • The product is with the mechanical sealing structure filled with the sealing material. It can be reopened and reused without changing sealing material.
  • Cable ports:4in 4out,Max capacity:192cores(single fiber)
  • The 3 types of cable rings(φ12.5,φ17,φ20) are optional according to users actual needs,effectively enhancing the reliability and practicability of cable port sealing.
  • The overlay structure of splice tray and the insulated grounding device make it more flexible, convenient and safer for optical cable configuration,dilatation and ground connection.
  • The external components and fastening parts are all made of stainless steel,It can be reopened and reused without changing sealing material.

The key technical indexes

  • Size(mm): 465 × 230×125
  • Weight:2.8kg
  • Fiber radius of curvature: ≥40mm
  • Splice tray additional losses:≤0.01dB
  • Storage fiber length:≥1.6m
  • Max capacity(single fiber): 192 cores
  • Working temperature: - 40℃ ~ + 70℃
  • Lateral pressure: ≥2000N / 10cm
  • Shock resistance:≥20N.m
